| Frameset |
| Frame |
Carbon Frame, 120mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fork |
Rockshox Reba RL, Motion Control, 130mm, 44mm offset |
| Rear Shock |
Rockshox SID LUX Select +, 190x45mm, standard |
| Drivetrain |
| Rear Shifter |
Shimano Deore SL-M6100, 12sp |
| Rear Derailleur |
Shimano Deore RD-M6100, 12sp, SGS |
| Crankset |
Shimano Deore FC-MT512, 32T, CL55, 165mm (S1), 170mm (S2,S3), 175mm (S4,S5) |
| Bottom Bracket |
Shimano BB-MT501, BSA 73mm |
| Cassette |
Shimano Deore CS-M6100-12, 10-51T, 12sp |
| Chain |
Shimano Deore CN-M6100-12, 12sp |
| Brakes |
| Front Brake |
Shimano Deore BR-MT410, 2-Piston, Resin Pads |
| Front Brake Rotor |
Shimano SM-RT64, 180mm, C-lock |
| Rear Brake |
Shimano Deore BR-MT410, 2-Piston, Resin Pads |
| Rear Brake Rotor |
Shimano SM-RT64, 180mm, C-lock |
| Brake Levers |
Shimano Deore M4100 |
| Components |
| Handlebar |
Norco 6061, 760mm (S1,S2,S3) / 780mm (S4,S5), 20mm rise |
| Stem |
Norco 6061, 50mm, 35mm Clamp |
| Seatpost |
TranzX YSI36, 31.6mm, 120mm (S1,S2), 150mm (S3), 170mm (S4), 200mm (S5) |
| Headset |
FSA No 42/48ACB Integrated Headset, Tapered 1-1/8" - 1.5" |
| Saddle |
WTB Silverado Medium |
| Grips |
WTB Wavelength |
| Seatpost Clamp |
Norco bolted, 34.9mm ID |
| Wheels |
| Front Hub |
Shimano Deore HB-MT410, 15x110mm Boost, 32H, C-lock |
| Rear Hub |
Shimano Deore FH-MT510, 12x148 Boost, Microspline, 32H, C-lock |
| Rims |
WTB ST i27 TCS, 27mm ID, 32H, 29" |
| Front Tire |
Maxxis New Forekaster, EXO, TR, 29x2.40" |
| Rear Tire |
Maxxis Rekon, EXO, TR, 29x2.40" |
| Rear Hub Skewer |
148mm x 12mm TA, L174, TL13, M12x1.6 |
| Spokes/Nipples |
Stainless steel |
| Valves |
WTB tubeless valves |
| Sealant |
Stans 250ml sealant |
| Weight |
| Weight |
13.64 kg (30 lbs) |
