| Frame |
Aluminum, Tig Welding, 10x135mm QR, Tapered HT |
| Fork |
Suntour XCT-30 DS Coil, 100mm, 46mm offset, 9x100 QR |
| Drivetrain |
| Rear Shifter |
Shimano Altus SL-M315, 8sp |
| Rear Derailleur |
Shimano Essa RD-U2000, 8sp Shadow |
| Crankset |
Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket |
Cartridge, ST 73mm, 113mm axle length |
| Cassette |
Shimano CS-HG400-8, 11-45T, 8spd |
| Chain |
KMC Z8 |
| Brakes |
| Front Brake |
C-Star BX-351, Mechanical Disc |
| Front Brake Rotor |
C-Star, 160mm, 6-Bolt |
| Rear Brake |
C-Star BX-351 Mechanical Disc |
| Rear Brake Rotor |
C-Star, 160mm, 6-Bolt |
| Brake Levers |
C-Star VL-801D Mechanical Disc |
| Components |
| Handlebar |
6062 Alloy DB 6.1, 760mm, 30mm rise |
| Stem |
Alloy 45mm Length, 31.8mm Clamp |
| Seatpost |
Alloy 31.6mm, 300mm length |
| Headset |
Zero Stack, 1-1/8" Steer, ZS44/28.6 | ZS44/30 1 1/8" |
| Headset Spacer |
3x10mm |
| Saddle |
Norco XC, Steel Rail |
| Grips |
DDK lock-On, 139mm length |
| Pedals |
Nylon Flat Pedal |
| Seatpost Clamp |
Norco Alloy QR, 34.9mm ID |
| Wheels |
| Front Hub |
Formula DC-1420, 9x100mm QR, 32h, 6-bolt |
| Rear Hub |
Formula DC-1422, 10x135mm QR, HG, 32h, 6-bolt |
| Rims |
DP 27 Rims, 27mm ID, 32H |
| Front Tire |
CY H-5162, 60TPI, Wire |
| Rear Tire |
CY H-5162, 60TPI, Wire |
| Spokes/Nipples |
Stainless Steel, 14g |
