| Frame |
SMOOTHWALL™ Carbon | Integrated Display | Mid-High Pivot Smoothlink Suspension | Press Fit BB | RIDE-4™ Adjustable Geometry | 145mm Travel | SMOOTHWALL™ Carbon Rear Triangle |
| Fork |
RockShox Lyrik Select | Delta RC Damper | 160mm |
| Fork Offset |
27.5”: 37mm | 29”: 42mm |
| Front Travel |
160mm |
| Shock |
SM–XL: RockShox Super Deluxe Select+ | Linear XL Air Can | 230x60mm
XS: RockShox Deluxe Ultimate | Linear XL Air Can | 210x55mm
Sealed Bearing Eyelet | 25x8mm Front Hardware |
| Rear Travel |
150mm |
| Headset |
FSA Orbit No.85 Reach Adjust | 0mm Cups Installed | ±5mm Cups Included | 36°x45° Bearings | 1.5” Crown Race |
| Stem |
Rocky Mountain 35 AM | 0° Rise | 40mm |
| Handlebar |
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35mm Clamp |
| Grips |
ODI Elite Pro Lock-On |
| Brakes |
Shimano XT Trail | 4-Piston | Metal Pads |
| Shifter |
Shimano XT |
| Rear Derailleur |
Shimano XT |
| Crankset |
Race Face Turbine Cinch | 34T | 30mm Spindle | 165mm |
| Bottom Bracket |
Race Face BB92 | 30mm |
| Cassette |
Shimano Deore | 10–51T | 12-Speed |
| Chain |
Shimano M6100 |
| Front Hub |
Novatec D791SB | Sealed | 15x110mm Boost |
| Rear Hub |
Novatec MTB SL Pro | 12x148mm Boost |
| Spokes |
DT Swiss Competition | 2.0 / 1.8 / 2.0 |
| Rims |
WTB KOM Trail i30 TCS 2.0 | 28H |
| Tires |
Front: Maxxis Minion DHF | 2.5WT | 3C MaxxTerra | EXO+ | Tubeless Ready
Rear: Maxxis Minion DHR II | 2.4WT | 3C MaxxTerra | EXO+ | Tubeless Ready |
| Seatpost |
TranzX +RAD2.0 Adjustable Dropper | 30mm Adjustment | Alloy I-Spec EV Lever | 30.9mm
XS: 120mm | SM: 150mm | MD: 170mm | LG: 200mm | XL: 230mm |
| Saddle |
WTB Volt Fusion Form 142 | Cromoly Rails |
| Drive System |
Dyname S4 Lite eMTB Drive | 250W Nominal | 700W Max | 75Nm | Rocky Mountain Micro Remote | Low RPM High Efficiency | Designed in Canada |
| Battery |
480Wh Removable Integrated Li-Ion |
| Remote |
Rocky Mountain Micro Remote |
| Display |
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
| Charger |
Rocky Mountain Powerplay FAST Charger | 4A | 48V | Higo Deep Socket Connector |
