Ready for camping trips with the family and the gravel paths of your neighbourhood. If you’re going to ride, ride in style.
Specification
| Frame |
Rocky Mountain 6061 Alloy | Threaded BB | Zero Stack Tapered Headtube | Dropper Post Compatible. Rear Triangle
|
| Fork |
Suntour XCM34 Boost 120mm
|
| Bottom Bracket |
Sealed Cartridge Bearing
|
| Headset |
Rocky Mountain | Loose Ball Bearings | 1.5" Crown Race
|
| Stem |
Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 40mm
|
| Handlebar |
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
|
| Saddle |
Rocky Mountain 148 Steel
|
| Seatpost |
Rocky Mountain 30.9mm
|
| Grips |
Rocky Mountain Lock On Light
|
| Rear Derailleur |
MicroShift Advent X 10spd With Clutch
|
| Crank |
Rocky Mountain Microdrive 3PC | 30T |76mm Asymmetrical BCD | Crank Length: XS-SM-MD = 170-mm | LG - XL = 175mm
|
| Shifters |
MicroShift Advent X 10spd
|
| Cassette |
Shimano Deore 11-46T 10spd
|
| Chain |
KMC X10-1
|
| Brakes |
Shimano MT4100 2 Piston | Resin Pads | F:Shimano RT10 160mm | R:Shimano RT10 160mm
|
| Rims |
Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape / Valves / Sealant Not Incl
|
| Spokes |
2.0 Stainless
|
| Front Hub |
Rocky Mountain Boost 15mm
|
| Rear Hub |
Shimano TX505
|
| Tires |
F: Kenda Amrak 27.5 x 2.4 // R: Kenda Amrak 27.5 x 2.4
|
Geometry
|
XS |
SM |
MD |
LG |
| Top Tube Horizontal (mm) |
561 |
586 |
610 |
638 |
| Head Tube Angle (deg) |
66 |
66 |
66 |
66 |
| Head Tube Length (mm) |
95 |
95 |
100 |
110 |
| Seat Tube Angle (deg) |
74.5 |
74.5 |
74.5 |
74.5 |
| Seat Tube Length (mm) |
345 |
380 |
420 |
445 |
| Rear Centre (mm) |
430 |
430 |
430 |
430 |
| Bottom Bracket Drop (mm) |
48 |
48 |
48 |
48 |
| Reach (mm) |
397 |
422 |
445 |
470 |
| Stack (mm) |
592 |
592 |
596 |
605 |
| Standover Height (mm) |
748 |
754 |
767 |
776 |
| Wheelbase (mm) |
1110 |
1135 |
1159 |
1189 |
SIze Guide
These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size.
| Size |
Height Range |
| XS |
152cm – 165cm |
| SM |
160cm – 170cm |
| MD |
167cm – 180cm |
| LG |
177cm – 188cm |
